Niveland^® 10

Technical Caracteristics

Product based on cements, selected aggregates, fibers, and additives.

Advantages and Uses

• Levelling mortar for interior irregular floors.
• High mechanical strength.
• Easy to apply and great self-levelling power.
• Smoothing of floors in interior residential buildings with moderate pedestrian traffic, prior to the installation of the final floor covering: ceramic tiles, parquet, PVC, linoleum, etc.
• Suitable for underfloor heating systems where levelling over a pre-existing screed is required.

Suitable Substrates

• Concrete, cementitious screeds  with  suitable resistances and others. Please ask our technical department for other substrates.
• Substrates must be resistant enough, stable, sound, and clean, free of dust, release agents, organic products, etc.
• If necessary, the substrate must be prepared by mechanical means, to obtain a surface free of surface grout with a suitable porosity.
• Before applying NIVELAND 10 make sure all holes and / or cracks are previously repaired by using products from our PAVILAND or MORCEMREST range,  according to  the nature of the substrate and the type of repair required.
• Apply Paviland Primer R to prevent the formation of air bubbles in the render and to improve adhesion to the substrate, following the instructions in the technical data sheet for this product.
• Before applying the mortar, make sure that residual  humidity is under the recommended one (below 3%).

Application Procedure

• Mix the product with water (5.0-5.5 litres per 25 kg bag) with a mechanical mixer at low speed (500 rpm approximately) until getting a homogeneous paste without lumps. The exact water dosage is especially important to avoid product segregation,  increased shrinkage, and reduced strength.
• Let the paste rest around 2 min. then mix again.
• The pot life of the mixture is 30 minutes, depending on environmental conditions.
• Pour the mixed product and spread it with a levelling trowel.
• The maximum recommended thickness is 10 mm, although up to 20 mm may be applied in localised areas or small sections (maximum 10 m² or 5 linear metres), provided that the substrate is resistant enough .
• Respect structural joints and create perimeter and partition joints.
• NIVELAND 10 should be protected. It is not a suitable to remain uncovered.

Recommendations

• Do not apply the product under temperatures of 5º nor above 30º.
• Do not apply if there is risk of frost, rain, heavy wind, or direct sun light.
• Do not apply outdoor.
• Do not apply on humid floors or if there is risk of having moisture.
• Do not add sand, cement, or any other material that may alter the original formulation.
• Once the product has been mixed, and its resting time has elapsed, do not add any water.
• For floors with surfaces larger than 20 m² or more than 10 linear meters, it is recommended to create expansion joints, dividing sections, with joints of about 6 mm which can be filled with PUMALASTIC MS or PU.
• The expansion joints of the original substrate must be respected, and perimeter joints should be created.
• The surface layer should be protected from an extremely fast drying, specially under elevated temperatures or / and heavy winds.
• Before applying the final flooring, residual moisten of the floor should be previously checked to make sure it is suitable for the floor to be installed.

Packaging and Storage

25kg laminated paper bags.
1 year storage in its original packaging, away from extreme weather conditions and humidity.

Technical data

(Statistic results were obtained under standard conditions).

CE Mark

GRUPO PUMA ESPAÑA, S.L Avda. AGRUPACIÓN CÓRDOBA, Núm. 17 14014 CÓRDOBA 26
NIVELAND 10 No. 501870-01 EN 13813 Fibre-reinforced cement-based self-levelling compound, type CT C25 F5, for the preparation of interior floors and the installation of light floor coverings such as ceramic tiles, parquet, carpet, etc., for thicknesses from 2 to 10 mm.
Reaction to fire	A1 Type
Hazardous substances emission	CT
Compressive Strength Flexural Strength	C25 F6
Dangerous substances	Consult safety data sheet

Environmental Product Declaration (EPD)

This mortar has been elaborated with arid located close to our production centres, which has, reduce the emission of greenhouse effect gases thanks to transport and ISO 14001 certified production centres with environmental management, with a firm commitment to sustainability and respect for the environment.
Type III ecofriendly labelled mortar (The strictest one) verified Environmental Product Declaration by AENOR.

Notas

The instructions for use are given according to our tests and knowledge and do not imply any commitment by GRUPO PUMA nor free the consumer from the examination and verification of the products for their correct use. Claims must be accompanied by the original packaging to allow a proper traceability.

GRUPO PUMA is not responsible, in any case, for the application of its products or constructive solutions carried out by the application company or other parties involved in the process and / or execution of the work, limiting the responsibility of GRUPO PUMA exclusively to the damages directly attributable to the supplied products, individually or integrated in systems, due to failures in their manufacturing process.

In any case, the drafter of the work project, the technical management or the person responsible for the work, or collaterally the application company or other parties involved in the process and / or execution of the work, must ensure the suitability of the products addressing the characteristics of them, as well as the conditions, support and possible pathologies of the work in question.

The values obtained by GRUPO PUMAS's products or its constructive solutions that, as the case may be, are determined by the EN standards or any other regulation that applies to it in each case refers exclusively to the conditions specifically stipulated in said regulation and that are referred to, among others, to certain characteristics of the support, humidity and temperature conditions, etc. without being them required in the tests obtained under different conditions, all in accordance with the relevant regulation.
